Did you know that applying drafts to models containing rounds and chamfers is vastly enhanced in Creo?

With Creo 5.0, PTC enhanced the ability to apply drafts to design models containing rounds and chamfers. Select surfaces as references in the Draft surfaces collector of the draft feature. Rounds and chamfers are automatically detected and highlighted in a different color. Rounds and chamfers are then handled as they are in the Creo Parametric Flexible Modeling environment If... Continue Reading →

March 10, 2020 0

Did you know you cannot drag surface finishes off the model surfaces that are created flat to screen in Creo?

That's correct. Flat to screen surface finishes do not have a directional annotation plane and do not support an extension line. You cannot drag surface finishes off the model surfaces that are created flat to screen. In Creo, if the placement surface is planar, then you can drag surface finishes in the XY direction beyond... Continue Reading →

March 5, 2020 0

How do you indicate placement of datum target on a surface in Creo?

With PTC Creo 4.0, the dashed leader line option can be used to indicate the placement of datum target on surface on the far side of the drawing view. To set the dashed leader line, select the "Far side" option in the Datum Target tab as shown below About Datum Target ribbon The Datum Target ribbon in Creo... Continue Reading →

March 5, 2020 0

Did you know about these MBD related checks in Creo?

With Creo 6.0, PTC has enhanced ModelCheck to include additional checks for tolerances, annotations, features, and combined states. For example - Annotations that are not referencing any surfaces Annotations not included in any combined state ModelCheck can identify any combined states that are not following the naming conventions within the user defined list of names... Continue Reading →

March 4, 2020 0

How to quickly find similar geometric shapes and surfaces in Creo?

Starting with Creo Parametric 4.0, you can quickly find rounds, chamfers , sheet metal design objects from within a single, easy-to-use search tool. The Geometry Search tool allows searches based on geometry and design intent to Creo Flexible Modeling. Searches can be based on a seed surface or be defined without a seed. Search results appears in the Found... Continue Reading →

March 2, 2020 0

About User roles and licenses for Punditas AI?

Punditas AI Advisor supports 7 types of Users based on their License level and the Punditas Product they are using User typePunditas ProductSummaryLicense requirementsDemo UserPunditas User AdvisorDemo User has limited access to Punditas User functionality. Only one module (Insights Engine) is included No license neededTrial UserPunditas User AdvisorTrial User has access to most functionality within Punditas... Continue Reading →

March 1, 2020 0

What is Punditas AI?

Punditas is an Artificial Intelligence (AI) driven Knowledge Platform for CAD, PLM, IoT, ERP and other Enterprise Applications. Punditas AI delivers product knowledge and insights by discovering and curating content from 100's of sources across the product ecosystem The picture above shows the home page of Punditas AI for Creo Parametric. Home page in Punditas... Continue Reading →

March 1, 2020 0

Did you know about these hole placement enhancements in Creo?

Starting with Creo 4.0, you can place a hole using an axis or point and a surface as references, even if - the axis is not normal to the surface or the point is not on the surface. Note: you can define the orientation of the hole regardless of how the hole is placed. When... Continue Reading →

February 26, 2020 0

How do you drag surface finishes beyond placement surface in Creo?

In Creo, if the placement surface is planar, then you can drag surface finishes in the XY direction beyond the placement surface. An extension line is created in the XY-direction when you drag the surface finish off the reference surface as shown below You can drag the surface finish in the Z-direction even when it... Continue Reading →

February 26, 2020 0

Have you tried splitting surfaces in Creo?

In Creo, some shape surface sets that are selected for removal contain surfaces that are shared by shapes included in the surface set, and shapes that are not included in the surface set. The system automatically splits these shared surfaces so that only the portions of the shared surfaces that belong to the selected shapes... Continue Reading →

February 23, 2020 0
