Starting with Creo 7.0, there's better control over the placement of ordinate dimensions that are created in models and drawings. Prior to this Creo 7.0 release, when creating ordinate dimensions per ANSI standards, these dimensions would get placed when they are aligned with the baseline. However, this can now be controlled using "default_ansi_ord_dim_aligned" config option.... Continue Reading →

If you have a part with interfering bodies or an assembly with interfere hidden lines removed. You might also want to see a drawing for a part or assembly with interfering parts or components, correctly with hidden lines removed. Starting with Creo 7.0, you can use the below config option to accurately remove the Hidden... Continue Reading →

When you place a leader annotation on an edge, the normal or tangent leaders appear as soon as the cursor position is beyond the snapping angle threshold. You may turn off this snapping in order to place a leader annotation very close to a normal or a tangent placement without the snapping. With Creo  7.0.1.0,... Continue Reading →

With Creo 7.0, you can control the display of representation geometry without setting defined appearances or appearance states. This makes it easier to work with different types of geometry representations. You can select or clear the Boundary (B-rep) and Mixed check boxes to hide or show the type of geometry representation. To set the transparency for each representation type,... Continue Reading →
